Range/Series Overview
IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.AS110's sleek and sturdy, gas-spring controlled monitor arm enables wide range of ergonomics for your VESA (75 mm or 100 mm) supported monitor. Free up your desk with integrated cable management. Supports up to 32", 9 kg monitors and offers 320 mm height, 325 mm stretch, -45°/60° tilt, -90°/90° swivel and 360° pivot range for increased flexibility. Built in USB Hub provides an easy way to transmit data & charge your devices. The USB Hub is equipped with a USB 3.0 port supporting data transfer speed up to 5Gbps and a USB-C port supporting data transfer speed up to 5Gbps allowing you to transfer your favourite content & files in seconds. Use the integrated USB 3.0 male extension cords to connect your PC with the USB Hub, and boost your productivity with a clutter-free desk.
Features Summary
- Vesa Connection
Any monitor equipped with a VESA mounting grid (100x100 or 75x75) can easily be attached to the monitor arm. The VESA mounting system is a widely used solution that most monitors are equipped with. Four screws hold the monitor securely to the mount, by its centre of gravity. - Swivel & Tilt
Some monitor stands come with a limited tilt and swivel range. Using a monitor arm increases your monitor's range of motion dramatically: You can tilt the monitor in a wide range so it points upwards or downwards for the optimal viewing angle. The integrated swivel enables you to turn the display horizontally. - Durable Mechanical Spring
A mechanical spring tensioning system is built into the upper arm to match the weight of the monitor. More than 30,000 exercise tests, safer and stronger. - Cable Management
Using the detachable covers on the monitor arm, simply push through your cables inside the pre-allocated routes in the monitor arm. After fitting both power and display cables inside, close the covers and experience a tidy desk with neatly organised connections. Cables are kept in place even when moving the display or turning it into portrait mode. - C-Lamp or Grommet Mount attachment
Your new AOC monitor arm is guaranteed to fit onto your desk. With either the grommet mount or the c-lamp method, you can easily fasten the mount to your tabletop. Your monitor will be firmly secured and ready for every gaming action. - USB Hub
Built in USB Hub provides an easy way to transmit data & charge your devices. The USB Hub is equipped with a USB 3.0 port supporting data transfer speed up to 5Gbps and a USB-C port supporting data transfer speed up to 5Gbps allowing you to transfer your favorite content & files in seconds. Use the integrated USB 3.0 male extension cords to connect your PC with the USB Hub, and boost your productivity with a clutter-free desk.
Specification Summary
Product Description
AOC AS110DX mounting kit - adjustable arm - for LCD display - gas spring - black
Product Type
Mounting kit (adjustable arm) - desk-mountable
Mounting Components
Monitor arm, clamp mounting base, grommet mount
Integrated Devices
USB hub
Adjustable Depth
Up to 46 cm
Adjustable Height
Up to 32 cm
Adjustments
Height, pan, pivot, swivel, tilt, depth
Recommended Use
LCD display
Recommended Display Size
13"-31.5"
VESA Mounting Interface
100 x 100 mm, 75 x 75 mm
Package Content
Installation hardware kit
