APC Metered Rack PDU AP7821B - power distribution

Images Manuals

Images for illustrative purposes

APC Metered Rack PDU AP7821B

View all APC Power Strips | Adapters - Visit the APC Store (AP7821B) - (MME270B823)

Metered Rack PDU AP7821B - power distribution unit

Efficient power distribution
Advanced environmental adaptability
Comprehensive remote management

FREE Delivery on orders over €250

4 Available to Ship
Order within 15Hrs 44Mins for: FREE Delivery (8 Jun or 9 Jun)

€765.10 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

It is a metered rack PDU designed for 1U horizontal mounting. It supports a maximum current of 16A and operates at 208-230V. The PDU features 8 IEC 60320 C13 outlets and an 8.2-foot power cord with an IEC 60320 C20 plug. It has a load capacity of 3300 VA and includes a cord retention bracket, installation guide, and rack mounting brackets.

Specification Summary

Product Description

APC Metered Rack PDU AP7821B - power distribution unit

Device Type

Power distribution unit - rack-mountable

Cord Length

2.4 m

Rack Size

Weight

1.41 kg

Input Voltage

AC 100-240 V

Output Voltage

AC 200-240 V

Input Connectors

1 x power IEC 60320 C20

Output connectors

8 x power IEC 60320 C13

Networking

Ethernet 10/100

Remote Management Protocol

SNMP, Telnet, HTTP, SSH

Dimensions (WxDxH)

44.37 cm x 10.23 cm x 4.41 cm

Manufacturer Warranty

2-year warranty

Designed For

P/N: SCL500RM1U, SCL500RMI1U, SCL500RMI1UC, SCL500RMI1UNC, SMTL1000RMI2UC, SMTL750RM2UCNC, SMTL750RMI2UC, SMX1000C, SMX1500RM2UC, SMX1500RM2UCNC, SMX2KR2UX145, SMX3KR2UNCX145, SMX750C, SMX750CNC, SMX750CUS, SRTL2K2RM1UWC, SRTL2K2RM1UWNC, SRTL3KRM1UIC, SRTL3KRM1UINC, SRTL3KRM1UWC, SRTL3KRM1UWNC

Specifications

EAN / GTIN:

0731304331513

General

Device Type

Power distribution unit - rack-mountable

Height (Rack Units)

Cord Length

2.4 m

Power Device

Input Voltage

AC 100-240 V

Input Voltage Margin

± 10%

Frequency Required

50 - 60 Hz

Input Connectors

1 x power IEC 60320 C20

Power Output Connectors Details

8 x power IEC 60320 C13

Output Voltage

AC 200-240 V

Max Electric Current

16 A

Networking

Remote Management Interface

Ethernet 10/100

Remote Management Protocol

SNMP, Telnet, HTTP, SSH

Expansion / Connectivity

Interfaces

1 x management (Ethernet) - RJ-45 ¦ 1 x serial - RJ-11

Miscellaneous

Cables Included

Power cable 2.5 m

Features

LED display, current meter

Compliant Standards

FCC Class A certified, UL, VCCI, cUL, EN55022, ICES-003, VDE, EN55024, EAC, AS/NZS CISPR 22

Manufacturer Warranty

Service & Support

Limited warranty - 2 years

Environmental Parameters

Min Operating Temperature

-5 °C

Max Operating Temperature

45 °C

Humidity Range Operating

5 - 95% (non-condensing)

Dimensions & Weight

Width

44.37 cm

Depth

10.23 cm

Height

4.41 cm

Weight

1.41 kg

Dimensions & Weight (Shipping)

Shipping Width

46.99 cm

Shipping Depth

33.65 cm

Shipping Height

6.36 cm

Shipping Weight

2.38 kg

Compatibility Information

Designed For

P/N: AP7950B, AR106, AR106SH4, AR106SH6, AR109SH4, AR109SH6, AR112, AR112SH4, AR112SH6, AR2487G, AR3003, AR3003SP, AR3006, AR3006SP, AR3100W, AR3103, AR3103SP, AR3105SP, AR3105W, AR3106, AR3106SP, AR3107SP, AR3140G, AR3140W, AR3150SP, AR3150W, AR3155SP, AR3155W, AR3157SP, AR3300SP, AR3300W, AR3305SP, AR3305W, AR3307SP, AR3340G, AR3340W, AR3350SP, AR3350W, AR3355SP, AR3355W, AR3357SP, AR3357X674, AR4018IX429, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4024IX431, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4038IX432, AR8213, AR9300SP, AR9300SP-R, AR9307SP, AR9307SP-R, NBPD0160A, NBWL0355A, NBWL0356A, SCL400RMJ1U, SCL500RM1U, SCL500RM1UC, SCL500RM1UNC, SCL500RMI1U, SCL500RMI1UC, SCL500RMI1UNC, SMC1000-BR, SMC1000I-2UC, SMC1000I-BR, SMC1000IC, SMC15002U-BR, SMC1500-BR, SMC1500I2U-BR, SMC1500I-2UC, SMC1500I-BR, SMC1500IC, SMT2200I-AR, SMT2200IC, SMT2200R2I-AR, SMT2200RM2UC, SMT2200RMI2UC, SMT2200RMI2UNC, SMT3000I2U-BR, SMT3000I-AR, SMT3000IC, SMT3000R2I-6W, SMT3000R2I-AR, SMT3000RM2UC, SMT3000RMI2UC, SMT3000RMI2UNC, SMTL1000RM2UC, SMTL1000RMI2UC, SMTL750RM2UC, SMTL750RM2UCNC, SMTL750RMI2UC, SMX1000C, SMX1000US, SMX1500RM2UC, SMX1500RM2UCNC, SMX1500RMNCUS, SMX1500RMUS, SMX2000LVNCUS, SMX2000LVUS, SMX2200HVNC, SMX2200R2HVNC, SMX2200RMLVUS, SMX2KR2UX145, SMX3000HV-BR, SMX3000HVTUS, SMX3000LV2U-BR, SMX3000LVNCUS, SMX3000LVUS, SMX3000RMLVUS, SMX3KR2UNCX145, SMX3KRMLVNCUS, SMX750C, SMX750CNC, SMX750CUS, SMX750US, SRT1000RMXLA, SRT1000RMXLA-NC, SRT1000RMXLI, SRT1000RMXLI-NC, SRT10RMXLIX806, SRT1500RMXLA, SRT1500RMXLA-NC, SRT2200RMXLI, SRT2200RMXLI-NC, SRT2200XLI, SRT3000RMXLI, SRT3000RMXLI-NC, SRT3000RMXLW-IEC, SRT3000XLI, SRT3000XLW-IEC, SRT5KRMXLI-6W, SRT5KRMXLIM, SRT5KRMXLTUS, SRT5KRMXLW-TW, SRT6KRMXLI-6W, SRT6KRMXLIM, SRT8KRMXLT-IEC, SRT8KXLT-IEC, SRTL2K2RM1UWC, SRTL2K2RM1UWNC, SRTL3KRM1UIC, SRTL3KRM1UINC, SRTL3KRM1UWC, SRTL3KRM1UWNC, SUA2200ICH-45, SUA3000I-IN, SYAF16KRMICH, SYAF8KRMTX424
