APC NetShelter - automatic transfer switch - 2880

Images Manuals

Images for illustrative purposes

APC NetShelter

View all APC Power Strips | Adapters - Visit the APC Store (AP4453A) - (ECE7777778)

NetShelter - Automatic transfer switch (rack-mountable) - AC 120 V - 2880 VA - 1-phase - USB, Ethernet 10/100/1000 - input: power NEMA L5-30P 24A - output connectors: 16 (NEMA 5-20R 16A) - 2U - 2.43 m cord - black

Efficient power distribution
Comprehensive connectivity
Advanced remote management
Robust environmental compliance
User-friendly installation

FREE Delivery on orders over €250

0 Available to Ship
Restock 23-Jun-2026 Estimated, Out of Stock Prices are Estimated.

RRP ~~€1906.50~~

€1559.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

APC NetShelter Rack Automatic Transfer Switch (ATS) AP4453A is the Fifth-Generation range of high availability switches offering greater control of your IT equipment from Cloud to Edge. With Industry leading reliability, agility, and manageability the APC NetShelter Rack ATS provides redundant power to single-corded equipment loads in the IT rack. AP4452A is single phase 1U Rack ATS with 20A rated current, 120V rated voltage and 1920VA load capacity. For North America region, the Regulatory Derated Input Current is 24A. It comes with 2 NEMA L5-30P inlet and 10 NEMA 5-20R outlet sockets. This has been upgraded with APC NMC3 and various technical advancements for network port sharing, environmental monitoring and enhanced security. It has 2-years of standard warranty and 5-years of extended warranty for peace of mind and use for years to come. Users can access and configure Rack ATS through secure Web UI, SNMP, CLI and are fully compatible with EcoStruxure IT.

Features Summary

Efficient power distribution
The APC NetShelter automatic transfer switch ensures efficient power distribution with a power capacity of 2880 VA, accommodating a wide range of operating temperatures from -5°C to 45°C. Its integrated circuit breaker and short-circuit protection enhance reliability and safety.
Comprehensive connectivity
Featuring a universal I/O port, Gigabit Ethernet for monitoring, and multiple USB connections, this device offers comprehensive connectivity options. The inclusion of both power and serial cables facilitates easy integration into existing setups.
Advanced remote management
Equipped with Ethernet and USB interfaces for remote management, the APC NetShelter supports CLI and SNMP protocols. This allows for efficient monitoring and management of power distribution devices from a distance, ensuring optimal performance.
Robust environmental compliance
Adhering to multiple compliance standards including China RoHS, EN 55022 Class A, EU RoHS, FCC Part 15 A, REACH, and WEEE, this automatic transfer switch is designed for global use while prioritizing environmental responsibility.
User-friendly installation
With a rack-mountable form factor, included rack mounting kit, and a horizontal orientation, the APC NetShelter is designed for easy installation. Its front and rear mounting profile, along with a box package, ensures a user-friendly setup process.

Specification Summary

Product Description

APC NetShelter - automatic transfer switch - 2880 VA

Device Type

Automatic transfer switch - rack-mountable

Cord Length

2.43 m

Rack Size

Weight

6.33 kg

Input Wiring

1-phase

Input Voltage

AC 120 V

Output Voltage

AC 120 V

Power Capacity

2880 VA

Input Connectors

2 x power NEMA L5-30P 24A

Output connectors

16 x power NEMA 5-20R 16 A

Networking

USB, Ethernet 10/100/1000

Remote Management Protocol

SNMP, CLI

Included Accessories

Mounting kit, rack mounting brackets

Colour

Black

Dimensions (WxDxH)

43.2 cm x 23.6 cm x 8.8 cm

Manufacturer Warranty

2-year warranty

Specifications

EAN / GTIN:

731304432531

General

Device Type

Automatic transfer switch - rack-mountable

Height (Rack Units)

Cord Length

2.43 m

Colour

Black

Power Device

Input Voltage

AC 120 V

Input Voltage Range

AC 108 - 132 V

Input Voltage Margin

± 10%

Input Wiring

1-phase

Frequency Required

50/60 Hz

Input Connectors

2 x power NEMA L5-30P 24A

Power Output Connectors Details

16 x power NEMA 5-20R 16 A

Output Voltage

AC 120 V

Max Electric Current

30 A

Power Capacity

2880 VA

Circuit Protection

Circuit breaker

Networking

Remote Management Interface

USB, Ethernet 10/100/1000

Remote Management Protocol

SNMP, CLI

Expansion / Connectivity

Interfaces

1 x universal I/O port ¦ 1 x monitoring (Gigabit LAN) - RJ-45 ¦ 1 x USB - 4 pin USB Type A ¦ 1 x console - 5 pin Micro-USB Type B ¦ 2 x LAN - RJ-45

Miscellaneous

Included Accessories

Mounting kit, rack mounting brackets

Cables Included

2 x power cable - integrated - 2.43 m ¦ Serial cable - external

Rack Mounting Kit

Included

Features

Box package, horizontal orientation, front and rear mounting profile, short-circuit protection, LED indicators, LCD display

Compliant Standards

REACH, EN 55022 Class A, FCC Part 15 A, EU RoHS, China RoHS, WEEE

Manufacturer Warranty

Service & Support

Limited warranty - replace or repair - 2 years

Environmental Parameters

Min Operating Temperature

-5 °C

Max Operating Temperature

45 °C

Humidity Range Operating

5 - 95%

Dimensions & Weight

Width

43.2 cm

Depth

23.6 cm

Height

8.8 cm

Weight

6.33 kg
