APC Netshelter Rack Automatic Transfer Switch AP4450A

Images for illustrative purposes

APC Netshelter Rack Automatic Transfer Switch AP4450A

View all APC Power Accessories - Visit the APC Store (AP4450A) - (ECE7777782)

Netshelter Rack Automatic Transfer Switch AP4450A - Redundant switch (rack-mountable) - AC 100/120 V - 1440 VA - 1-phase - Ethernet 10/100/1000, USB - output connectors: 10 - 1U - 2.43 m cord - black

Efficient power management
Versatile connectivity options
Robust environmental adaptability
Comprehensive safety compliance
Easy installation and maintenance

FREE Delivery on orders over €250

1 Available to Ship
Order within 12Hrs 38Mins for: FREE Delivery (12 Aug or 13 Aug)

RRP ~~€1383.75~~

€1135.39 Incl Vat

Price at 30 Day Low

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

APC NetShelter Rack Automatic Transfer Switch (ATS) AP4450A is the Fifth-Generation range of high availability switches offering greater control of your IT equipment from Cloud to Edge. With Industry leading reliability, agility, and manageability the APC NetShelter Rack ATS provides redundant power to single-corded equipment loads in the IT rack. AP4450A is single phase 1U Rack ATS with 15A rated current, 100V/120V rated voltage and 1440VA load capacity. For North America region, the Regulatory Derated Input Current is 12A. It comes with 2 NEMA 5-15P inlet and 10 NEMA 5-15R outlet sockets. This has been upgraded with APC NMC3 and various technical advancements for network port sharing, environmental monitoring and enhanced security. It has 2-years of standard warranty and 5-years of extended warranty for peace of mind and use for years to come. Users can access and configure Rack ATS through secure Web UI, SNMP, CLI and are fully compatible with EcoStruxure IT.

Specification Summary

Product Description

APC Netshelter Rack Automatic Transfer Switch AP4450A - redundant switch - 1440 VA

Device Type

Redundant switch - rack-mountable

Cord Length

2.43 m

Rack Size

Weight

4.4 kg

Input Wiring

1-phase

Input Voltage

AC 100/120 V

Output Voltage

AC 100/120 V

Power Capacity

1440 VA

Input Connectors

2 x power NEMA 5-15P

Output connectors

10 x power NEMA 5-15R

Networking

Ethernet 10/100/1000, USB

Remote Management Protocol

SNMP, CLI

Included Accessories

Mounting kit, rack mounting brackets

Colour

Black

Dimensions (WxDxH)

43.18 cm x 23.62 cm x 4.4 cm

Manufacturer Warranty

2-year warranty

Specifications

EAN / GTIN:

731304432517

General

Device Type

Redundant switch - rack-mountable

Height (Rack Units)

Cord Length

2.43 m

Colour

Black

Power Device

Input Voltage

AC 100/120 V

Input Voltage Margin

± 10%

Input Wiring

1-phase

Frequency Required

50/60 Hz

Input Connectors

2 x power NEMA 5-15P

Power Output Connectors Details

10 x power NEMA 5-15R

Output Voltage

AC 100/120 V

Max Electric Current

15 A

Power Capacity

1440 VA

Networking

Remote Management Interface

Ethernet 10/100/1000, USB

Remote Management Protocol

SNMP, CLI

Expansion / Connectivity

Interfaces

1 x sensor ¦ 3 x LAN - RJ-45 ¦ 3 x USB - 4 pin USB Type A ¦ 1 x USB - 5 pin Micro-USB Type B

Miscellaneous

Included Accessories

Mounting kit, rack mounting brackets

Cables Included

2 x power cable - integrated - 2.43 cm ¦ Serial cable - external

Rack Mounting Kit

Included

Features

Horizontal orientation, LED indicators, LCD display

Compliant Standards

PSE Mark, TÜV safety certification, VCCI Class A, REACH SvHC, EU RoHS, China RoHS, WEEE

Manufacturer Warranty

Service & Support

Limited warranty - 2 years

Environmental Parameters

Min Operating Temperature

-5 °C

Max Operating Temperature

45 °C

Humidity Range Operating

5 - 95%

Dimensions & Weight

Width

43.18 cm

Depth

23.62 cm

Height

4.4 cm

Weight

4.4 kg

Dimensions & Weight (Shipping)

Shipping Width

60 cm

Shipping Depth

35.6 cm

Shipping Height

11.4 cm

Shipping Weight

6.17 kg
