Built-in Devices
Status LED
Features
Microsoft Teams compatible, Zoom compatible
Supported Display Graphics
HD (1280 x 720), 1280x800, 1366x768, 1440x900, 1600x900, UXGA (1600x1200), WSXGA+ (1680 x 1050), HDTV (1920x1080), UHD (3840 x 2160)
Connectivity Technology
Wired
Data Link Protocol
Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol
IPv4
Features
Auto-negotiation, auto-switching, auto-discovery, TCP/IP support, UDP support, DHCP support, full duplex mode, half duplex mode, SSH support, SFTP support, active directory native logon, HTTPS support, mDNS, LPCM support, PoE+, metal housing, vented sides, 2 mounting flanges attached
Compliant Standards
IEEE 802.3af, IEEE 802.1x
Expansion Slots
1 x microSD
Interfaces
1 x infrared - 2 pin terminal block ¦ 1 x serial - RS-232 - 5 pin terminal block ¦ 1 x audio - line-out - 5 pin terminal block ¦ 1 x audio / video - HDMI input - 19 pin HDMI Type A ¦ 1 x audio / video - HDMI output - 19 pin HDMI Type A ¦ 1 x USB 2.0 - 4 pin USB Type A ¦ 1 x SuperSpeed USB 3.0 - 9 pin USB Type A ¦ 1 x USB 2.0 - console - 4 pin USB Type B ¦ 2 x network - RJ-45
Compliant Standards
SSL, TLS, HDCP 2.2, HDCP 1.4, EDID compatible, CEC, AES, Intertek, FCC Part 15 B, IC
Voltage Required
AC 100-240 V (50/60 Hz)
Power Consumption Operational
14 Watt
Software / System Requirements
OS Required
Android, Apple iOS, Apple MacOS, Google Chrome OS, Microsoft Windows 10 / 11
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% RH (non-condensing)
