StarTech 2-Port Gigabit PoE+ Injector, PoE/PoE+ (802.3af/802.3at) 30W

Images for illustrative purposes

StarTech 2-Port Gigabit PoE+ Injector, PoE/PoE+ (802.3af/802.3at) 30W

View all STARTECH.COM Power Accessories - Visit the STARTECH.COM Store (AF221CE-POE-INJECTOR) - (ECE10475804)

StarTech 2-Port Gigabit PoE+ Injector, PoE/PoE+ (802.3af/802.3at) 30W - PoE injector - unmanaged inline - DC 48 - 52 V - 30 Watt - output connectors: 2 - United Kingdom, Europe - black

Robust protection features
Flexible connectivity options
Environmentally compliant
User-friendly design
Efficient network performance

FREE Delivery on orders over €250

20 Available to Ship
Order within 10Hrs 22Mins for: Delivery (8 Jun or 9 Jun)

€82.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The StarTech.com 2-Port Gigabit PoE+ Injector enables efficient Power over Ethernet (PoE) connectivity and is designed to support both PoE and PoE+ standards. With a power output of 30 watts, it can deliver reliable power alongside data, making it ideal for devices such as IP cameras and wireless access points. This unmanaged inline device is wall-mountable, which allows for flexible installation in various environments, from offices to server rooms. It operates within a broad temperature range of 0 °C to 60 °C, ensuring functioning in diverse conditions, while supporting humidity levels of 5% to 90% RH (non-condensing). The compact plastic housing offers EMI filtering and 2 kV surge protection for added reliability and safety.

Key features include wake on LAN and Preboot Execution Environment (PXE) support that enhance device management and boot options. The injector supports 9K jumbo frames, auto MDIX, and auto-negotiation for seamless network configuration. With dual Gigabit LAN ports that provide flexibility for connecting multiple devices, this injector adheres to various IEEE standards, including IEEE 802.3af and IEEE 802.3at, ensuring compatibility across a range of PoE devices.

Features Summary

Robust protection features
Equipped with 2 kV surge protection and 15 kV ESD protection (air) to safeguard devices from electrical surges and electrostatic discharge.
Flexible connectivity options
Includes two RJ-45 output connectors that allow for connections to multiple network devices, enhancing versatility in setup.
Environmentally compliant
Meets RoHS standards, ensuring that the product is free from hazardous substances and is safe for the environment.
User-friendly design
Features LED indicators that provide quick status updates for power and connectivity, facilitating easier monitoring.
Efficient network performance
Supports 9K jumbo frames and provides auto-negotiation capabilities to optimize throughput and performance in high-demand network environments.

Specification Summary

Product Description

StarTech 2-Port Gigabit PoE+ Injector, PoE/PoE+ (802.3af/802.3at) 30W - PoE injector - unmanaged inline - 30 Watt

Device Type

PoE injector - external

Power Over Ethernet (PoE)

PoE+

Weight

60 g

Localisation

United Kingdom, Europe

Input Voltage

DC 48 - 52 V

Output Voltage

DC 52 V

Power Capacity

30 Watt

Output connectors

2 x RJ-45 - 52 V 580 mA 30 W

Included Accessories

Power adapter

Colour

Black

Dimensions (WxDxH)

4.6 cm x 10.2 cm x 2.5 cm

Manufacturer Warranty

2-year warranty

Specifications

EAN / GTIN:

0065030911313

General

Device Type

PoE injector - external

Power Over Ethernet (PoE)

PoE+ (IEEE 802.3at)

Colour

Black

Localisation

United Kingdom, Europe

Power Device

Input Voltage

DC 48 - 52 V

Power Output Connectors Details

2 x RJ-45 - 52 V 580 mA 30 W

Output Voltage

DC 52 V

Power Capacity

30 Watt

Expansion / Connectivity

Interfaces

2 x Gigabit LAN (PoE+) - RJ-45 ¦ 2 x Gigabit LAN - RJ-45

Miscellaneous

Included Accessories

Power adapter

Features

Wall mountable, wake on LAN, Preboot Execution Environment (PXE) support, auto MDIX support, plastic housing, EMI filtering, 100 m maximum cable length, supports 9K jumbo frames, auto-negotiation, IP802AR chipset, 2 kV surge protection, LED indicator, 8 kV ESD protection (Contact), 15 kV ESD protection (Air)

Compliant Standards

IEEE 802.3u, IEEE 802.3i, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, RoHS, PSE Mark

Manufacturer Warranty

Service & Support

Limited warranty - 2 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

60 °C

Humidity Range Operating

5 - 90% RH (non-condensing)

Dimensions & Weight

Width

4.6 cm

Depth

10.2 cm

Height

2.5 cm

Weight

60 g

Dimensions & Weight (Shipping)

Shipping Width

20.7 cm

Shipping Depth

14.4 cm

Shipping Height

3.8 cm

Shipping Weight

105 g
