Brother ADS-4100 - document scanner - desktop - US

Images Manuals

Images for illustrative purposes

Brother ADS-4100

View all BROTHER Document Scanners - Visit the BROTHER Store (ADS4100ZU1) - (WCEADS4100ZU1)

ADS-4100 - document scanner - desktop - USB 3.0, USB 2.0 (Host)

Efficient duplex scanning
Versatile document handling
Advanced image optimization
Robust connectivity options

FREE Delivery on orders over €250

Note: All Brother Printers/Scanners come with 1 Year Standard Warranty.

4 Available to Ship
Order within 16Hrs 53Mins for: FREE Delivery (8 Jun or 9 Jun)

€419.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Simple and intuitive. This highly versatile scanner is ideal for businesses that need to digitise a wide range of media, from paper to plastic cards, whether at home or in the office.

Specification Summary

Product Description

Brother ADS-4100 - document scanner - desktop - USB 3.0, USB 2.0 (Host)

Device Type

Document scanner - desktop

Interface Type

USB 3.0, USB 2.0 (Host)

Scanning Sensor Type

Contact Image Sensor (CIS)

Light Source

LED

Additional Functions

Scan to PC, scan to image

Max Supported Document Size

215.9 x 355.6 mm

Input Type

Colour

Grayscale / Color Depth

8-bit (256 colours) / 48-bit colour

Grayscale / Color Depth (External)

24-bit (16.7 million colours)

Optical Resolution

600 dpi x 600 dpi

Interpolated Resolution

1200 dpi x 1200 dpi

Max Document Scan Speed

35 ppm (mono) / 35 ppm (colour)

Max Document Size

215.9 mm x 355.6 mm

Automatic Duplexing

Yes

Supported Document Type

Plain paper, business card, plastic card

Document Feeder Type

Automatic

Document Storage Capacity

60 sheets

Duty Cycle

5250 scans per day

Power

AC 100-240 V (50/60 Hz)

System Requirements

Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Apple macOS 10.14.x or later, Microsoft Windows 7 (32/64 bits) SP1, Windows 8.1 (32/64 bits), Windows 10 (32/64 bits)

Dimensions (WxDxH)

29.95 cm x 19.05 cm x 21.59 cm

Weight

2.6 kg

Manufacturer Warranty

1-year warranty

Specifications

EAN / GTIN:

4977766814485

General

Type

Document scanner - desktop

Interface Type

USB 3.0, USB 2.0 (Host)

Additional Functions

Scan to PC, scan to image

Max Supported Document Size

215.9 x 355.6 mm

Scanner

Input Type

Colour

Grayscale Depth

8-bit (256 colours)

Colour Depth

48-bit colour

Colour Depth (External)

24-bit (16.7 million colours)

Optical Resolution

600 dpi x 600 dpi

Interpolated Resolution

1200 dpi x 1200 dpi

Automatic Duplexing

Yes

Scanning Sensor Type

Contact Image Sensor (CIS)

Bulb / Light Source Type

LED

Max Document Scan Speed B/W

35 ppm

Max Document Scan Speed Colour

35 ppm

Duty Cycle

5250 scans per day

Scanner Speed Details

35 ppm - black & white - A4 ¦ 35 ppm - colour - A4 ¦ 70 ipm - duplex - black & white ¦ 70 ipm - duplex - colour

Scanner Features

Long Document Scanning, auto image rotation, Auto Deskew, automatic page size detection, Automatic Separation, blank page skipping, One-Touch button, Remove Background

Compliant Standards

ICA, TWAIN, WIA, SANE

Media Handling

Max Document Size

215.9 mm x 355.6 mm

Supported Document Type

Plain paper, business card, plastic card

Supported Document Size Details

ADF - up to 215.9 x 355.6 mm

Document Feeder Type

Automatic

Document Storage Capacity

60 sheets

Expansion / Connectivity

Interfaces Details

USB 2.0 (Host) - Type A ¦ USB 3.0

Miscellaneous

Cables Included

1 x USB cable

Compliant Standards

RoHS, GS, WHQL

Power

Power Device

Internal power supply

Voltage Required

AC 100-240 V (50/60 Hz)

Power Consumption Operational (Standby)

23 Watt

Power Consumption Stand by

5.4 Watt

Power Consumption Sleep

1.4 Watt

Software / System Requirements

Software Included

Presto! BizCard 7, Presto! BizCard 6, NewSoft Presto! ImageFolio

OS Required

Dimensions & Weight

Width

29.95 cm

Depth

19.05 cm

Height

21.59 cm

Weight

2.6 kg

Dimensions & Weight (Shipping)

Shipping Width

39.1 cm

Shipping Depth

32 cm

Shipping Height

24.3 cm

Shipping Weight

3.31 kg

Manufacturer Warranty

Service & Support

Limited warranty - 1 year

Environmental Parameters

Min Operating Temperature

5 °C

Max Operating Temperature

35 °C

Humidity Range Operating

20 - 80%

Sound Emission

59 dB
