ASUS TUF GAMING B650E-PLUS WIFI

Name: ASUS TUF GAMING B650E-PLUS WIFI
Brand: ASUSTEK
SKU: WCE90MB1M20M0EAY0
Price: 203.87 EUR
Availability: InStock

View all ASUSTEK AMD Desktop Motherboards - Visit the ASUSTEK Store (90MB1M20-M0EAY0) - (WCE90MB1M20M0EAY0)

Model: ASUS

ASUS TUF GAMING B650E-PLUS WIFI - motherboard - ATX - Socket AM5 - AMD B650

Connectivity options
Audio output
Power design
Cooling options
Memory capabilities

FREE Delivery on orders over €250

5 Available to Ship
Order within 4Hrs 20Mins for: Delivery (8 Jun or 9 Jun)

€203.87 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The ASUS TUF GAMING B650E-PLUS WIFI motherboard is designed to deliver performance and reliability for gaming and high-performance computing setups. Equipped with the AMD B650 chipset and support for Ryzen processors, this motherboard facilitates processing capabilities. With four DIMM slots for DDR5 RAM, users can enjoy memory architecture and speeds that can be overclocked. Its connectivity options, including USB 3.2, USB-C, HDMI, and DisplayPort, ensure seamless integration with various devices.

Specification Summary

Product Description

ASUS TUF GAMING B650E-PLUS WIFI - motherboard - ATX - Socket AM5 - AMD B650

Product Type

Motherboard - ATX

Chipset Type

AMD B650

Processor Socket

1 x Socket AM5

Compatible Processors

Ryzen (supports Ryzen 7000/8000/9000 Series)

Max RAM Size

192 GB

RAM Supported

4 DIMM slots - DDR5, non-ECC, on-die ECC, ECC, unbuffered

Storage Ports

4 x SATA-600 (RAID), 3 x M.2

USB / FireWire Ports

1 x USB-C 3.2 Gen 2 + 1 x USB 3.2 Gen 2 + 3 x USB 3.2 Gen 1 + 3 x USB 2.0 + (1 x USB-C Gen 2x2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)

Audio

HD Audio (8-channel)

LAN

802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3, 2.5 Gigabit Ethernet

Specifications

EAN / GTIN:

4711387995488

General

Product Type

Motherboard - ATX

Chipset Type

AMD B650

Processor Socket

Socket AM5

Max Processors Qty

Compatible Processors

Ryzen (supports Ryzen 7000/8000/9000 Series)

Supported RAM

Max Size

192 GB

Technology

DDR5

Bus Clock

4000 MHz (O.C.), 3900 MHz (O.C.), 3800 MHz (O.C.), 3600 MHz (O.C.), 3500 MHz (O.C.), 3400 MHz (O.C.), 3300 MHz (O.C.), 3200 MHz (O.C.), 3100 MHz (O.C.), 3000 MHz (O.C.), 2900 MHz (O.C.), 2800 MHz (O.C.), 2700 MHz (O.C.), 2600 MHz, 2500 MHz, 2400 MHz

Supported RAM Integrity Check

Non-ECC, on-die ECC, ECC

Registered or Buffered

Unbuffered

Features

Dual channel memory architecture, AMD EXPO technology

Audio

Type

HD Audio (8-channel)

Compliant Standards

High Definition Audio

LAN

Network Interfaces

802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3, 2.5 Gigabit Ethernet

Expansion / Connectivity

Expansion Slots

1 x CPU ¦ 4 x DIMM 288-pin ¦ 2 x PCIe 4.0 x16 ¦ 2 x M.2 socket (2280 M.2 slot) ¦ 1 x M.2 socket (22110 M.2 Key M slot)

Storage Interfaces

SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 5.0 -connectors: 1 x M.2 ¦ PCIe 4.0 -connectors: 2 x M.2

RAID Features

AMD RAID Xpert2 Technology

Interfaces

1 x HDMI ¦ 1 x DisplayPort ¦ 2 x aerial ¦ 1 x USB 3.2 Gen 2 ¦ 1 x USB-C 3.2 Gen 2 ¦ 3 x USB 3.2 Gen 1 ¦ 3 x USB 2.0 ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x audio line-in - mini-jack

Internal Interfaces

1 x USB-C 3.2 Gen 2x2 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 4 x USB 2.0 - header ¦ 1 x serial - header ¦ 1 x audio - header

Power Connectors

24-pin main power connector, 4-pin ATX12V connector, 8-pin ATX12V connector

Features

BIOS Type

AMI

Sleep / Wake Up

Wake on LAN (WOL), wake on PME

Hardware Features

ASUS 5X Protection III, LANGuard, ASUS DIGI+ VRM, ASUS SafeSlot, ASUS Stainless Steel Back I/O, overvoltage protection, Q-Antenna, Q-DIMM, Q-LED Core, Q-Slot, ASUS EZ DIY, BIOS FlashBack button, BIOS FlashBack LED, VRM heatsink design, M.2 heatsink, 8+2 Phase Power Design, ASUS Enhanced Memory Profile (AEMP)

Miscellaneous

Included Accessories

2 x M.2 SSD screw package, ASUS Wi-Fi moving aerial, 1 x M.2 rubber package, TUF certification card

Cables Included

2 x Serial ATA cable

Software Included

Armoury Crate, ASUS AURA Creator, ASUS Fan Xpert 4, ASUS TurboV EVO Utility, PC Cleaner, ASUS DriverHub, ASUS TUF GAMING CPU-Z, DTS Audio Processing, Adobe Creative Cloud (free trial), Norton 360 for Gamers (60 days trial), WinRAR (40 days trial)

Width

30.5 cm

Depth

24.4 cm
