Product Type
Motherboard - micro ATX
Processor Socket
LGA1700 Socket
Compatible Processors
(supports 12th and 13th Generation Intel Core / Pentium Gold / Celeron)
Bus Clock
4800 MHz, 5000 MHz (O.C.), 5200 MHz (O.C.), 5400 MHz (O.C.), 5600 MHz (O.C.), 5800 MHz (O.C.), 6000 MHz (O.C.), 6200 MHz (O.C.)
Supported RAM Integrity Check
Non-ECC
Registered or Buffered
Unbuffered
Features
Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)
Type
HD Audio (8-channel)
Compliant Standards
High Definition Audio
Network Interfaces
Gigabit Ethernet
Expansion Slots
1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 4.0 x16 ¦ 2 x PCIe 3.0 x1 ¦ 2 x M.2 socket (2242/2260/2280 M.2 Key M slot) ¦ 1 x M.2 socket (Key E)
Storage Interfaces
SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 4.0 -connectors: 2 x M.2
RAID Features
Intel Rapid Storage Technology
Interfaces
1 x HDMI ¦ 1 x VGA ¦ 2 x DisplayPort ¦ 2 x USB 3.2 Gen 1 ¦ 2 x USB 2.0 ¦ 1 x PS/2 keyboard ¦ 1 x PS/2 mouse ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x microphone - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack
Internal Interfaces
4 x USB 2.0 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x USB-C 3.2 Gen 1 - header ¦ 1 x audio - header ¦ 1 x SPI - header ¦ 1 x speaker - header ¦ 1 x serial - header
Power Connectors
24-pin main power connector, 8-pin ATX12V connector
Sleep / Wake Up
Wake on PME, wake on LAN (WOL)
Hardware Features
Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Technology 2.0, LANGuard, ASUS Q-Design, Q-DIMM, Q-LED Core, Q-Slot, ASUS EZ DIY, ASUS Self Recovering BIOS, ASUS Event Log, anti-moisture coating, overcurrent protection, audio jack detect technology, jack retasking, Preboot eXecution Environment (PXE), Windows 11 compatible, ASUS OptiMem II
Included Accessories
IO shield, M.2 screw package, M.2 Key E screw package, ACC Express Activation Key Card
Cables Included
2 x Serial ATA cable
Software Included
ASUS Control Center Express
