EAN / GTIN:
4711081453314
Product Type
Motherboard - ATX
Processor Socket
Socket AM4
Compatible Processors
Ryzen (supports Ryzen 3000 Series/ 4000 G-Series/ 5000 Series/ 5000 G-Series)
Bus Clock
2400 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 3200 MHz, 3400 MHz (O.C.), 3466 MHz (O.C.), 3600 MHz (O.C.), 3733 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4266 MHz (O.C.), 4400 MHz (O.C.), 4600 MHz (O.C.), 4666 MHz (O.C.), 4800 MHz (O.C.), 4866 MHz (O.C.), 5100 MHz (O.C.)
Supported RAM Integrity Check
ECC, non-ECC
Registered or Buffered
Unbuffered
Features
Dual channel memory architecture
Type
HD Audio (8-channel)
Audio Codec
SupremeFX (S1220A)
Compliant Standards
High Definition Audio, DTS Sound Unbound
Network Controller
Intel I255-V
Network Interfaces
2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.2
Expansion Slots
1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 4.0 x16 ¦ 1 x PCIe 3.0 x16 (x4 mode) ¦ 3 x PCIe 3.0 x1
Storage Interfaces
SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 ¦ SATA-600 / PCIe 3.0 -connectors: 2 x M.2
Interfaces
1 x LAN (2.5Gigabit Ethernet) ¦ 4 x USB 3.2 Gen 1 ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x USB-C Gen2 ¦ 1 x USB 3.2 Gen 2 ¦ 1 x TOSLINK ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 2 x USB 2.0 ¦ 1 x DisplayPort ¦ 1 x HDMI
Internal Interfaces
4 x USB 2.0 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x Thunderbolt - header ¦ 1 x audio - header
Power Connectors
4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector
BIOS Features
BIOS FlashBack, UEFI BIOS
Sleep / Wake Up
Wake on LAN (WOL), wake on PME
Hardware Features
Preboot eXecution Environment (PXE), CrashFree BIOS 3, ASUS TurboV EVO, ASUS Fan Xpert 4, ASUS EPU (Energy Processing Unit), ASUS DIGI+ VRM, ASUS Aura Sync, Sonic Radar III, Sonic Studio III, GameFirst VI, ASUS SafeSlot, pre-mounted I/O shield, ASUS ProCool, M.2 heatsink, ASUS Q-Design, Q-DIMM, Q-LED, Q-Slot, jack retasking, audio jack detect technology, 12+2 Phase Power Design, SupremeFX Shielding technology, ASUS EZ DIY
Included Accessories
External antenna, cable ties, 1 x M.2 screw, ROG fan stickers, ROG thank you card, rubber pad, RGB Addressable LED extension cable, ROG key chain
Cables Included
4 x Serial ATA cable
Software Included
ASUS AI Suite III, WinRAR, DAEMON Tools, Norton AntiVirus (Trial), ASUS EZ Update, ASUS EZ Flash 3, AIDA64 Extreme (60 days trial), Overwolf, Antivirus, Sonic Studio Virtual Mixer, ROG CPU-Z, ASUS ROG RAMCache III
