Startech HPE 747698-B21 Compatible QSFP+ Module, 40GBASE-SR4, 40GbE Multi Mode Fiber Optic Transceiver, 40GE Gigabit Ethernet QSFP+, MPO 400m, 850nm,

Images for illustrative purposes

Startech HPE 747698-B21 Compatible QSFP+ Module, 40GBASE-SR4, 40GbE Multi Mode Fiber Optic Transceiver, 40GE Gigabit Ethernet QSFP+, MPO 400m, 850nm,

Name: Startech HPE 747698-B21 Compatible QSFP+ Module, 40GBASE-SR4, 40GbE Multi Mode Fiber Optic Transceiver, 40GE Gigabit Ethernet QSFP+, MPO 400m, 850nm,
Brand: STARTECH.COM
SKU: ECE10309383
Price: 56.56 EUR
Availability: OutOfStock

View all STARTECH.COM Repeaters | Tranceivers - Visit the STARTECH.COM Store (747698-B21-ST) - (ECE10309383)

Startech HPE 747698-B21 Compatible QSFP+ Module, 40GBASE-SR4, 40GbE Multi Mode Fiber Optic Transceiver, 40GE Gigabit Ethernet QSFP+, MPO 400m, 850nm, DDM, HPE BladeSystem, c-Class - Lifetime Warranty (747698-B21-ST) - QSFP+ transceiver module (equivalent

FREE Delivery on orders over €250

0 Available to Ship
Restock 22-Jun-2026 Estimated, Out of Stock Prices are Estimated.

€56.56 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

40 Gbps | Multi Mode Fiber | MPO | 400 m (1312 ft.) | Lifetime Warranty. The 747698-B21-ST is a HP 747698-B21 compatible fiber transceiver module that has been designed, programmed and tested to work with HP brand switches and routers. It delivers dependable 40 GbE connectivity over fiber cable, for 40GBase-SR4 compliant networks, with a maximum distance of up to 400 m (1312 ft.).

Technical Specifications:

Wavelength: 850nm

Maximum Data Transfer Rate: 40 Gbps

Type: Multi Mode Fiber

Connection Type: MPO Connector

Maximum Transfer Distance: 400 m (1312 ft.)

MTBF: 244,610,583 hours

Power Consumption: Low power consumption

Digital Diagnostics Monitoring (DDM): Yes

This QSFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & QSFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of QSFP+ modules and direct-attach QSFP+ cables, providing the convenience and reliability you need to ensure dependable network performance.

Specification Summary

Product Description

Device Type

QSFP+ transceiver module - MPO multi-mode

Form Factor

Plug-in module

Cabling Type

40GBASE-SR4

Data Transfer Rate

40 Gbps

Optical Wave Length

850 nm

Data Link Protocol

40GbE

Max Transfer Distance

400 m

OEM Manufacturer Equivalent Part Number

HP 747698-B21

Dimensions (WxDxH)

12.2 cm x 1.86 cm x 0.85 cm

Weight

37.5 g

Manufacturer Warranty

Limited lifetime warranty

Specifications

EAN / GTIN:

0065030886208

General

Device Type

QSFP+ transceiver module

Form Factor

Plug-in module

Networking

Connectivity Technology

Wired

Cabling Type

40GBASE-SR4

Data Link Protocol

40GbE

Data Transfer Rate

40 Gbps

Optical Wave Length

850 nm

Max Transfer Distance

400 m

Features

Digital Diagnostics Monitoring (DDM)

Expansion / Connectivity

Interfaces

1 x Ethernet 40GBASE-SR4 - MPO multi-mode female

Miscellaneous

MTBF

244,610,583 hours

Compliant Standards

MSA

OEM Manufacturer Equivalent Part Number

HP 747698-B21

Dimensions & Weight

Width

12.2 cm

Depth

1.86 cm

Height

0.85 cm

Weight

37.5 g

Dimensions & Weight (Shipping)

Shipping Width

12 cm

Shipping Depth

20.5 cm

Shipping Height

3.5 cm

Shipping Weight

60 g

Manufacturer Warranty

Service & Support

Limited warranty - lifetime
