Overview

Range/Series Overview


IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Need a 10GbE NIC with features to help you speed up your HPE Blade server? The HPE 530FLB is a dual-port 10GbE adapter, featuring the next generation, single-chip 10 Gb Ethernet solution from QLogic in a FlexibleLOM form factor designed for HPE BladeSystem c-Class Gen8 servers. The HPE 530FLB FlexibleLOM adapter delivers full line-rate performance across all ports with low power consumption. The HPE 530FLB provides high performance Ethernet connectivity with support for HPE Virtual Connect Flex-10 interconnect technology, allowing the benefits of virtualization to extend beyond the server and into the rest of the infrastructure. The HPE 530FLB supports enterprise class features such as VLAN tagging, adaptive interrupt coalescing, MSI-X, NIC teaming (bonding), Receive Side Scaling (RSS), jumbo frames, PXE boot, and virtualization features such as VMware NetQueue and Microsoft VMQ. Support for HPE Sea of Sensors Technology enhances server performance while reducing energy use and expense.


Specification Summary

Product Description
HPE 530FLB - network adapter - PCIe 2.0 x8 - 2 ports
Device Type
Network adapter
Interface (Bus) Type
PCI Express 2.0 x8
Ports Qty
2 ports
Data Link Protocol
100Mb LAN, 1GbE, 10GbE
Data Transfer Rate
10 Gbps
Processor
1 x Broadcom BCM57810S
RAM
900 MB
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap
System Requirements
SunSoft Solaris 10, Microsoft Windows HPC Server 2008 SP2, Microsoft Windows Server 2008 R2 SP1, Red Hat Enterprise Linux 6.1, Red Hat Enterprise Linux 5.7
Designed For
ProLiant BL420c Gen8, BL460c Gen8, BL465c Gen8, BL660c Gen8, BL660c Gen8 Performance, WS460c Gen8, WS460c Gen8 Graphics Expansion

Specifications

EAN / GTIN:
4948382828040
General
Device Type
Network adapter - 2 ports
Interface (Bus) Type
PCI Express 2.0 x8
Networking
Connectivity Technology
Wired
Data Link Protocol
Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Data Transfer Rate
10 Gbps
Features
VLAN support, TCP/IP offloading, QoS, Jumbo Frames support, PXE support, RSS
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap
Processor / Memory
Processor
1 x Broadcom BCM57810S
RAM
900 MB
Expansion / Connectivity
Compatible Slots
1 x FlexibleLOM
Miscellaneous
Compliant Standards
FCC Class A certified, VCCI, EN55022, ICES-003, IEC 60950, EN55024, UL 60950, CSA 22.2 No. 60950, MIC, AS/NZS 3548, FCC CFR47 Part 15, WEEE, RoHS, ACA
Software / System Requirements
OS Required
SunSoft Solaris 10, Microsoft Windows HPC Server 2008 SP2, Microsoft Windows Server 2008 R2 SP1, Red Hat Enterprise Linux 6.1, Red Hat Enterprise Linux 5.7
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
55 °C
Humidity Range Operating
10 - 90% (non-condensing)
Compatibility Information
Designed For
HPE ProLiant BL420c Gen8, BL460c Gen8, BL465c Gen8, BL660c Gen8, BL660c Gen8 Performance, WS460c Gen8, WS460c Gen8 Graphics Expansion
