EAN / GTIN:
3553340620935
Device Type
UPS - rack-mountable / external
UPS Technology
Line interactive
Input Voltage
AC 200/208/220/230/240 V
Input Voltage Range
AC 160 - 294 V
Input Voltage Range (Adjustable)
AC 150 - 294 V
Frequency Provided
50/60 Hz ± 0.1Hz
Frequency Required
40 - 70 Hz
Input Connectors
1 x power BS
Power Output Connectors Details
8 x power IEC 60320 C13 ¦ 2 x power IEC 60320 C19
Output Voltage
AC 200/208/220/230/240 V 50/60 Hz
Power Capacity
3000 Watt / 3000 VA
Run Time (Up To)
68 min at 300 Watts ¦ 39 min at 500 Watts ¦ 23 min at 800 Watts ¦ 13 min at 1200 Watts ¦ 7 min at 1800 Watts ¦ 4 min at 2500 Watts
Features
Maintenance free
Remote Management Interface
Ethernet 10/100/1000, RS-232, USB
Remote Management Protocol
SNMP 1, SNMP 3, IPv6, IPv4, HTTP, HTTPS, DHCP, NTP, SMTP, SMTPS, SSH, CLI
Interfaces
1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x management (USB) - 4 pin USB Type B ¦ 1 x remote power (on/off) - mini terminal block ¦ 1 x remote power off - mini terminal block ¦ 1 x relay output - mini terminal block ¦ 1 x management (Gigabit Ethernet) - RJ-45 ¦ 1 x USB - 4 pin USB Type A ¦ 1 x management (USB) - Micro-USB Type B
Expansion Slots
1 (total) / 0 (free) x Expansion Slot
Included Accessories
Tower stand
Cables Included
3 x power cable - external ¦ USB cable - external ¦ Serial cable - external
Rack Mounting Kit
Included
Features
LCD display, Automatic Voltage Regulation (AVR), Advance Battery Management (ABM), automatic self-test, deep discharge protection, automatic shut down
Compliant Standards
EN 62040-1, IEC 62040-1, EN 62040-2, IEC 62040-2, EN 62040-3, IEC 62040-3, RoHS, REACH, UL 1778, CSA 22.2, cTUVus, EAC, CM, UKCA, KCC
Sustainability Information
Service & Support
Limited warranty - 3 years ¦ Limited warranty - batteries - 2 years
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
0 - 90% (non-condensing)
