Eaton 5PX G2 1440VA 1440W 120V Line-Interactive UPS

Images for illustrative purposes

Eaton 5PX G2 1440VA 1440W 120V Line-Interactive UPS

Name: Eaton 5PX G2 1440VA 1440W 120V Line-Interactive UPS
Brand: EATON
SKU: ECE6882446
Price: 1569.75 EUR
Availability: OutOfStock

View all EATON Uninteruptable Power Supply - Visit the EATON Store (5PX1500RTG2) - (ECE6882446)

Model: Eaton 5PX

5PX G2 1440VA 1440W 120V Line-Interactive UPS - 8 NEMA 5-15R Outlets, Cybersecure Network Card Option, Extended Run, 2U Rack/Tower Battery Backup - UPS (rack-mountable / external) - AC 120 V - 1440 watt - 1440 VA - RS-232, USB - output connectors: 8

Efficient Power Management
Flexible Connectivity Options
Optimal Performance in Various Conditions
Space-Saving Design

FREE Delivery on orders over €250

**Note: There may be an extra delivery charge on some very large UPS, we will notify you if this is the case. Please ensure you are buying the correct UPS or Battery, once a UPS or Battery is opened it cannot be returned. Please contact sales through email, chat or phone if you need to confirm.

0 Available to Ship
Restock 07-Jul-2026 Estimated, Out of Stock Prices are Estimated.

€1569.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The new Eaton 5PX Gen2 UPS provides Enterprise Networks and Edge IT equipment with best-in-class line-interactive power protection maximizing IT space and Service Continuity. Eaton 5PX Gen 2 offers powerful tools to remotely monitor, integrate with IT architecture and remotely deploy / maintain large installed base of UPSs.

Specification Summary

Product Description

Eaton 5PX G2 1440VA 1440W 120V Line-Interactive UPS - 8 NEMA 5-15R Outlets, Cybersecure Network Card Option, Extended Run, 2U Rack/Tower Battery Backup - UPS - 1440 watt - 1440 VA

Device Type

UPS - rack-mountable / external

Rack Size

Weight

23 kg

Input Voltage

AC 120 V

Output Voltage

AC 120 V

Power Capacity

1440 watt / 1440 VA

Input Connectors

1 x power NEMA 5-15P

Output connectors

8 x power NEMA 5-15R

Battery

Lead Acid

Run Time (Up To)

5 min at full load

Networking

RS-232, USB

Included Accessories

Tower stand

Colour

Black, silver

Dimensions (WxDxH)

43.7 cm x 44.7 cm x 8.64 cm

Environmental Standards

ENERGY STAR

Manufacturer Warranty

3-year warranty

Specifications

EAN / GTIN:

743172105776

General

Device Type

UPS - rack-mountable / external

Height (Rack Units)

Colour

Black, silver

Power Device

UPS Technology

Line interactive

Input Voltage

AC 120 V

Input Voltage Range

AC 100 - 125 V

Frequency Provided

50/60 Hz

Frequency Required

50/60 Hz

Input Connectors

1 x power NEMA 5-15P

Power Output Connectors Details

8 x power NEMA 5-15R

Output Voltage

AC 120 V 50/60 Hz

Power Capacity

1440 watt / 1440 VA

Output Waveform

Sinewave

Surge Suppression

Yes

Surge Energy Rating

380 joules

Efficiency

98%

Battery

Technology

Lead Acid

Run Time (Up To)

5 min at full load ¦ 15 min at half load

Features

Sealed, maintenance free, valve-regulated

Networking

Remote Management Interface

RS-232, USB

Expansion / Connectivity

Interfaces

1 x management (RS-232) - RJ-45 ¦ 1 x management (USB) - 4 pin USB Type B

Expansion Slots

1 (total) / 1 (free) x Expansion Slot

Miscellaneous

Included Accessories

Tower stand

Cables Included

USB cable - external ¦ RS-232 cable - external ¦ Power cable 3.05 m

Rack Mounting Kit

Included

Features

Advance Battery Management (ABM), LCD display, hot-swappable batteries, cold-start function

Compliant Standards

cULus, NOM, RoHS, REACH, IEC 62040-1

Sustainability Information

ENERGY STAR

Yes

Manufacturer Warranty

Service & Support

Limited warranty - 3 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

20 - 90% (non-condensing)

Dimensions & Weight

Width

43.7 cm

Depth

44.7 cm

Height

8.64 cm

Weight

23 kg
