Device Type
Solid state drive - hot-swap
Encryption Algorithm
256-bit AES
NAND Flash Memory Type
3D triple-level cell (TLC)
Features
64-layer cell structure, S.M.A.R.T.
Drive Writes Per Day (DWPD)
1
Drive Transfer Rate
600 MBps (external)
Internal Data Rate
540 MBps (read) / 520 MBps (write)
4KB Random Read
95000 IOPS
4KB Random Write
22000 IOPS
Non-Recoverable Errors
1 per 10^17
Interfaces
1 x SATA 6 Gb/s
Power Consumption
6 Watt (typical)
Compliant Standards
TUV, EN 60950, RRL, IEC 60950, IC, RoHS, UL 60950-1 Second Edition, KCC, BSMI CNS 13438, RCM, WEEE 2002/96/EC, FCC CFR47 Part 15 B Class B, EN 55032 Class B, CISPR 32 Class B, AS/NZS CISPR32 Class B, Micron Green Standard, VCCI 2015.04 Class B, ICES-003:2016
Dimensions & Weight (Shipping)
Service & Support
Limited warranty - 1 year
Min Operating Temperature
0 °C
Max Operating Temperature
70 °C
Humidity Range Operating
5 - 95% (non-condensing)
Shock Tolerance (non-operating)
1500 g @ 0.5 ms
Vibration Tolerance (non-operating)
3.13 g @ 5-800 Hz
Compatibility Information
Designed For
Lenovo ThinkAgile VX 2U Certified Node (2.5") ¦ Lenovo ThinkSystem SD530 (2.5") ¦ Lenovo ThinkSystem SN550 (2.5") ¦ Lenovo ThinkSystem SN850 (2.5") ¦ Lenovo ThinkSystem SR530 (2.5") ¦ Lenovo ThinkSystem SR550 (2.5") ¦ Lenovo ThinkSystem SR570 (2.5") ¦ Lenovo ThinkSystem SR590 (2.5") ¦ Lenovo ThinkSystem SR630 (2.5") ¦ Lenovo ThinkSystem SR650 (2.5") ¦ Lenovo ThinkSystem SR850 (2.5") ¦ Lenovo ThinkSystem SR860 (2.5") ¦ Lenovo ThinkSystem SR950 (2.5") ¦ Lenovo ThinkSystem ST550 (2.5")
