Ergotron LX Pro mounting kit

View all ERGOTRON Monitor Mounts, Arms & Stands - Visit the ERGOTRON Store (45-683-293) - (ECE11548489)

Single monitor arm, wall mounted - For screens sized up to 34" - Weight Capacity: 4 to 22 lbs (1.8 to 10 kg). Display depth greater than 3.6" (9 cm) may affect weight capacity - Dark grey - Wall-mountable (wall mount base, fasteners for wood stud or concr

Ergonomic adjustments
Secure mounting
Clean installation

FREE Delivery on orders over €250

1 Available to Ship
Order within 0Hrs 23Mins for: Delivery (8 Jun or 9 Jun)

€193.25 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The Ergotron LX Pro is a modular mounting kit designed for LCD displays of up to 34 inches. Made from durable aluminum, this mounting kit provides stability with a maximum load weight of 10 kg. It supports various adjustments including tilt, pan, rotation, and lift, allowing for optimal viewing angles and comfort. The integrated cable management system keeps your workspace organized and clutter-free, enhancing both functionality and appearance. This product is wall-mountable and compliant with OSHPD and HCAI standards, making it a reliable choice for any professional or home setting.

Specification Summary

Product Description

Ergotron LX Pro mounting kit - modular - for LCD display - dark grey

Product Type

Mounting kit (modular) - wall-mountable

Mounting Components

Monitor arm

Tilt

85°

Pan

360°

Lift

33 cm

Rotation

360°

Adjustments

Pan, tilt, rotation, lift

Weight

2.59 kg

Recommended Use

LCD display

Recommended Display Size

Up to 34"

VESA Mounting Interface

100 x 100 mm, 75 x 75 mm

Max Load Weight

10 kg

Material

Aluminium

Colour

Dark grey

Manufacturer Warranty

10 years warranty

Specifications

EAN / GTIN:

00698833091625

General

Weight

2.59 kg

Material

Aluminium

Colour

Dark grey

AV Furniture

Type

Mounting kit

Mounting Components

Monitor arm

Design

Modular

Recommended Use

LCD display

Placing / Mounting

Wall-mountable

VESA Mounting Interface

100 x 100 mm, 75 x 75 mm

Cable Management

Integrated cable management

Recommended Display Size

Up to 34"

Tilt

85°

Pan

360°

Lift

33 cm

Rotation

360°

Adjustments

Pan, tilt, rotation, lift

Max Load Weight

10 kg

Min Load Weight

1.8 kg

Dimensions & Weight Details

Shipping Dimensions (WxDxH) / Weight

53.5 cm x 18.5 cm x 16.5 cm / 3.67 kg

Compliant Standards

HCAI, OSHPD

Manufacturer Warranty

Service & Support

Limited warranty - 10 years
