EAN / GTIN:
4002888383455
Device Type
Video/audio/infrared/serial extender
Connectivity Technology
Wired
Data Link Protocol
HDBaseT
Max Resolution
3840 x 2160 @ 60 Hz
Max Transfer Distance
150 m
Features
Power over cable (PoC), EDID Management, HDR support, 18 Gbps bandwidth, 4K60 8-bit 4:4:4 compatible, EDID Pass-Through, 5.1 channel audio support, downscaler function, HDMI loop out, metal housing
Compliant Standards
HDCP 2.2
Interfaces
4 x HDMI input (transmitter) - Type A female ¦ 5 x IR input (transmitter) - mini jack female ¦ 4 x HDMI output (transmitter) - Type A female ¦ 4 x audio line-out (transmitter) - RCA female ¦ 4 x audio line-out (transmitter) - 5 pin Phoenix female ¦ 4 x HDBaseT output (transmitter) - RJ-45 female ¦ 1 x RS-232 (transmitter) - DB-9 female ¦ 1 x serial (transmitter) - RJ-45 female ¦ 1 x HDMI output (receiver) - Type A female ¦ 1 x IR output (receiver) - mini jack female ¦ 1 x IR input (receiver) - mini jack female ¦ 1 x HDBaseT (receiver) - RJ-45 female ¦ 1 x audio line-out (receiver) - mini jack female ¦ 1 x RS-232 (receiver) - 3 pin Phoenix
Included Accessories
4 x 3-pin terminal block, 4 x 5-pin terminal block, 10 mounting brackets, 4 power cables, 10 screws
Cables Included
5 x IR emitter cable - 1.5 m ¦ 5 x IR receiver cable - 1.5 m ¦ 1 x RS-232 cable - 1.5 m
Compliant Standards
UKCA, FCC, RoHS, REACH, CP65
Power Device
Internal power supply
Power Consumption Operational
60 Watt
Dimensions (WxDxH) / Weight Details
Matrix extender: 44 cm x 20 cm x 4.5 cm ¦ Receiver: 14 cm x 6.5 cm x 1.8 cm
Dimensions & Weight (Shipping)
Service & Support
Limited warranty - 2 years
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 90% RH (non-condensing)
