Range/Series Overview
IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.Continuously emulates VGA EDID information
Supports resolutions up to 1920x1200@60Hz
For use with 32120 for cloning
Powered via VGA Source Interface, 3.5/1.35mm Optional DC jack for non-powered source devices
2 Year warranty
The Lindy VGA EDID Emulator is designed for systems that require EDID signals to be continuously provided without interruption and helps overcome EDID related problems which can occur when using AV/KVM extenders, switches and splitters. It can also be used in place of a monitor to keep the graphics card of a PC or server awake for remote access via IP. With support for resolutions up to 1920x1200@60Hz, the emulator is suitable for use with legacy PCs and displays. When used with the Lindy EDID recorder (32120) this device can provide cloned EDID information to the graphics card.
It is also possible to use the Emulator without cloning a display as it comes complete with pre-set EDID data for the most commonly used resolution/timing combinations, please see the Technical Information section for a full breakdown.
Features Summary
- Reliable performance
This EDID emulator ensures that VGA devices communicate effectively by accurately replicating the EDID information from displays, helping to maintain optimal resolution and performance. - Versatile environmental tolerance
Designed to function in temperatures between 0°C and 50°C, this emulator can adapt to a variety of environments, whether in a controlled studio or a more variable production setting. - Efficient power requirements
Operating on a low voltage power supply of DC 5 V, the Lindy VGA EDID Emulator delivers effective performance while consuming minimal energy, making it an economical choice for users. - Easy connectivity
Equipped with both VGA input and output terminals, the emulator facilitates straightforward connections with various VGA devices, ensuring compatibility and reliable data transmission.
Specification Summary
Product Description
Lindy VGA EDID Emulator EDID emulator
Dimensions (WxDxH)
4.8 cm - 2.2 cm - 7.3 cm
Manufacturer Warranty
2 years
