Startech - Docking station - for tablet, laptop - USB-C / USB4 / Thunderbolt 3 / Thunderbolt 4 / Thunderbolt 5 / USB-A - HDMI, DP - 1GbE - 180 Watt - TAA Compliant - United Kingdom, Europe

Advanced Display and Charging Capabilities
Networking and Compatibility
Secure and High-Functioning Workspace
Enterprise Management Tools

FREE Delivery on orders over €250

114 Available to Ship
Order within 15Hrs 28Mins for: FREE Delivery (11 Aug or 12 Aug)

€274.82 Incl Vat

Price at 30 Day Low

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Simplify your workspace with this high-performance dock for Thunderbolt 5, Thunderbolt 4, and USB4 laptops. Connect up to three 4K 144Hz displays or dual 8K 60Hz via HDMI, DisplayPort, and USB-C outputs. The dock provides 140W laptop charging with a 180W power adapter, plus a 30W USB-C port for phone or tablet charging. Built-in SD 4.0 and microSD 4.0 slots enable fast transfers from UHS-II cards. A 3.5mm audio jack supports headsets or speakers, and dual security slots (K-Slot and Nano) help protect the dock in shared or high-traffic setups. 2.5GbE RJ45 port for fast and reliable networking. Fully compatible with Windows 11 and macOS 15 / 26, the driverless design simplifies deployment. StarTech.com Connectivity Tools add manageability features like MAC address pass-through and Wi-Fi auto-switch. Download the Connectivity Tools to support device management and increase productivity in modern IT environments. With features such as MAC address pass-through, Wi-Fi auto-switch, and USB device monitoring, the software helps IT teams streamline deployment and enhance security across diverse setups.

Specification Summary

Product Description

Startech - docking station - USB-C / USB4 / Thunderbolt 3 / Thunderbolt 4 / Thunderbolt 5 / USB-A - HDMI, DP - 1GbE - TAA Compliant

Product Type

Docking station - for tablet, laptop

Docking Interface

USB-C / USB4 / Thunderbolt 3 / Thunderbolt 4 / Thunderbolt 5 / USB-A

Video Interfaces

HDMI, DP

Dimensions (WxDxH)

15 cm x 14 cm x 5 cm

Weight

592 g

Colour

Space grey

Localisation

United Kingdom, Europe

Networking

Gigabit Ethernet

Power

Power adapter 180 Watt Power Provided (DC 20 V)

TAA Compliant

Yes

Manufacturer Warranty

3-year warranty

Specifications

EAN / GTIN:

0065030923118

General

Product Type

Docking station - for tablet, laptop

Width

15 cm

Depth

14 cm

Height

5 cm

Weight

592 g

Enclosure Colour

Space grey

Localisation

United Kingdom, Europe

Video

Max Resolution Details

7680 x 4320 - 60 Hz (Dual Display) ¦ 3810 x 2160 - 60 Hz (Triple Display)

Networking

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Compliant Standards

IEEE 802.3bz, USB 3.2 Gen 2, USB 3.2 Gen 1, USB4

Expansion / Connectivity

Expansion Slots

1 (total) / 1 (free) x SD Memory Card ¦ 1 (total) / 1 (free) x microSD

Interfaces

1 x display / video - DisplayPort - 20 pin DisplayPort ¦ 1 x display / video - HDMI - 19 pin HDMI Type A ¦ 2 x USB-C 3.2 Gen 2 - 24 pin USB-C ¦ 1 x USB 3.2 Gen 2 - 9 pin USB Type A ¦ 2 x USB 3.2 Gen 1 - 9 pin USB Type A ¦ 1 x network - 100Base-TX/1000Base-TX/2.5GBase-T - RJ-45 ¦ 1 x audio - headphones/microphone - mini-phone stereo 3.5 mm 4-pole ¦ 1 x Thunderbolt 5 ¦ 1 x Thunderbolt 4/USB4

Miscellaneous

Input Device

SD card reader, microSD card reader

Cables Included

1 x Thunderbolt 5 cable - external - 80 cm

Features

Security lock slot (cable lock sold separately), wake on LAN, Preboot Execution Environment (PXE) support, full duplex support, up to 40Gbps data transfer, power LED status, up to 3 external displays, up to 140W power delivery, UASP support

Security Slot Type

Kensington nano security slot / Kensington security slot

Compliant Standards

Plug and Play, RoHS, WEEE, Thunderbolt 3, Thunderbolt 4, USB Power Delivery 3.1, Thunderbolt 5

TAA Compliant

Yes

Power

Power Device

Power adapter

Power Provided

180 Watt

Voltage Provided

DC 20 V

System Requirements

OS Required

Windows 11, Apple macOS 15

Manufacturer Warranty

Service & Support

Limited warranty - 3 years

Dimensions & Weight (Shipping)

Shipping Width

30.2 cm

Shipping Depth

16.9 cm

Shipping Height

5.9 cm

Shipping Weight

1.8 kg

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C
