ASUSTEK

ASUS PRIME B550M-A ...

ASUS PRIME B550M-A - Motherboard - micro ATX - Socket AM4 - AMD B550 Chipset - USB 3.2 Gen 1, USB 3.2 Gen 2 - Gigabit LAN - onboard graphics (CPU required) - HD Audio (8-channel) (90MB14I0-M0EAY0)

  •   Tune it your way
  •   Cool to the core
  •   VRM heatsink and thermal pads
  •   Build on a solid foundation
  •   Achieve speed with onboard M.2
  •   Little things make a big difference
  • View More
  •   Combined onboard features deliver elevated audio
Manufacturer Logo
80  Available to Ship
Quantity
Increase Quantity Decrease Quantity
Lowest Price in 30 Days!
€ 149.97   Incl Vat



FREE Delivery on orders over €150
Order in the next 1Hrs 58Mins for:
Delivery (31 Mar or 3 Apr)


Wishlist Add to Wishlist
Elara SKU: ECE5766457    |   Manufacturer SKU: 90MB14I0-M0EAY0
Refresh     Add to Compare Add to compare     Print Page Print Page
ASUS PRIME B550M-A Overview

Range/Series Overview


IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, Prime B550 series motherboards provide daily users and DIY PC builders a range of performance tuning options via intuitive software and firmware features.

Features Summary

  • Tune it your way
    Comprehensive controls form the foundation of the ASUS Prime series. The Prime B550 motherboard packs flexible tools to tune every aspect of your system, enabling you to tweak performance settings to perfectly match the way you work - maximizing your productivity.
  • Cool to the core
    Prime B550 series is engineered with multiple onboard heatsinks and an array of hybrid fan headers to ensure your rig stays cool and stable under intense workloads.
  • VRM heatsink and thermal pads
    A VRM heatsink with underneath thermal pad improves heat transfer from the MOSFETs and chokes for better cooling performance.
  • Build on a solid foundation
    Prime B550 motherboard provides all the fundamentals to boost daily productivity, so your system will be ready for action with stable power, intuitive cooling and flexible transfer options.
  • Achieve speed with onboard M.2
    PCIe 4.0 M.2 Slot supports up to 22110 and provide NVMe SSD RAID support for an incredible performance boost.
  • Little things make a big difference
    Prime B550 series adds the nuanced details that improve every experience, from exclusive codecs that provide pristine audio quality to intuitive RGB lighting controls that let you customize your system to create a uniquely personal look.
  • Combined onboard features deliver elevated audio
    Intelligent design and premium hardware create audio quality unlike anything you've ever experienced.




ASUS PRIME B550M-A Features
Product Description
ASUS PRIME B550M-A - motherboard - micro ATX - Socket AM4 - AMD B550
Product Type
Motherboard - micro ATX
Chipset Type
AMD B550
Processor Socket
1 x Socket AM4
Compatible Processors
Ryzen (supports 3rd Generation Ryzen)
Max RAM Size
128 GB
RAM Supported
4 DIMM slots - DDR4, ECC, unbuffered
Storage Ports
4 x SATA-600 (RAID), 2 x M.2
USB / FireWire Ports
2 x USB 3.2 Gen 2 + 4 x USB 3.2 Gen 1 + (2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)
Audio
HD Audio (8-channel)
LAN
Gigabit Ethernet
ASUS PRIME B550M-A Specifications
General
Product Type
Motherboard - micro ATX
Chipset Type
AMD B550
Processor Socket
Socket AM4
Max Processors Qty
1
Compatible Processors
Ryzen (supports 3rd Generation Ryzen)
Supported RAM
Max Size
128 GB
Technology
DDR4
Bus Clock
2400 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3466 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4400 MHz (O.C.), 3200 MHz
Supported RAM Integrity Check
ECC
Registered or Buffered
Unbuffered
Audio
Type
HD Audio (8-channel)
Audio Codec
Realtek ALC887
Compliant Standards
High Definition Audio
LAN
Network Controller
Realtek RTL8111H
Network Interfaces
Gigabit Ethernet
Expansion / Connectivity
Expansion Slots
1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 4.0 x16 ¦ 2 x PCIe 3.0 x1
Storage Interfaces
SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 ¦ SATA-600 / PCIe 4.0 -connectors: 1 x M.2 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x M.2
Interfaces
1 x VGA ¦ 1 x DVI-D ¦ 1 x LAN (Gigabit Ethernet) ¦ 4 x USB 3.2 Gen 1 ¦ 2 x USB 3.2 Gen 2 ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x PS/2 keyboard / mouse ¦ 1 x HDMI
Internal Interfaces
4 x USB 2.0 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x SPDIF out - header ¦ 1 x audio - header ¦ 1 x serial - header ¦ 1 x speaker - header
Power Connectors
24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Type
AMI
BIOS Features
UEFI BIOS, ASUS EZ Flash 3
Sleep / Wake Up
Wake on LAN (WOL)
Hardware Features
Jack retasking, ASUS Q-Design, ASUS TurboV EVO, Q-DIMM, ASUS EZ DIY, Q-Slot, CrashFree BIOS 3, audio jack detect technology, ASUS EPU (Energy Processing Unit), ASUS DIGI+ VRM, Preboot eXecution Environment (PXE), ASUS Stainless Steel Back I/O, ASUS Fan Xpert 2+, LANGuard, ASUS Overvoltage Protection, Lighting Control, ASUS 5X Protection III, ASUS SafeSlot Core, ASUS Aura Sync, Armoury Crate
Miscellaneous
Included Accessories
1 x M.2 screw, I/O back cover
Cables Included
2 x Serial ATA cable
Software Included
Drivers & Utilities, ASUS AI Charger, ASUS CPU-Z, ASUS AI Suite III, ASUS EZ Update, DAEMON Tools, WinRAR, Norton AntiVirus (60 days trial)
Width
24.4 cm
Depth
24.4 cm
ASUS PRIME B550M-A Essential Bundles
Options
ASUS PRIME B550M-A Reviews



0 Reviews |

Add review for ASUS PRIME B550M-A
Find Similar to ASUS PRIME B550M-A


Form Factor : Micro ATX
CPU Socket : Socket AM4
Max Memory(RAM) : 128 GB
RAM Technology : DDR4 SDRAM
OnBoard Graphics ? : Graphics adapter (CPU required)
OnBoard Sound ? : Sound card
No. Of Supported CPUs : 1
Chipset : AMD B550
Storage Interface : Serial ATA-600 (RAID)
Storage Interface : M.2 socket
Networking : Ethernet
Brand: ASUSTEK
Stock                             Status: In Stock
Price Range: €100 - €200
