Type
Point of sale terminal
Recommended Use
Small business, corporate business
Product Form Factor
All-in-one
Built-in Devices
Stereo speakers, display
Embedded Security
Trusted Platform Module (TPM) Security Chip
Localisation
English / United Kingdom
CPU
Intel Core i3 (2nd Gen) 2120 / 3.3 GHz
Number of Cores
Dual-Core
CPU Upgradability
Upgradable
Chipset Type
Intel Q67 Express
Installed Size
4 GB / 16 GB (max)
Technology
DDR3 SDRAM - non-ECC
Effective Memory Speed
1333 MHz
Rated Memory Speed
1600 MHz
Memory Specification Compliance
PC3-12800
Form Factor
SO-DIMM 204-pin
Configuration Features
1 x 4 GB
Type
1 x SATA - integrated
Native Resolution
1024 x 768 (XGA)
Horizontal Viewing Angle
160
Vertical Viewing Angle
140
Image Brightness
350 cd/m²
Image Contrast Ratio
700:1
Monitor Features
Projected Capacitive Touch (PCT) technology, 52% colour gamut
Graphics Processor
Intel HD Graphics 2000
Compliant Standards
SRS Premium Sound, High Definition Audio
Speakers Included
2 x right / left channel
Ethernet Controller
Intel 82579LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
ASF 2.0
Features
Wake on LAN (WoL), PXE support, auto-uplink (auto MDI/MDI-X)
Compliant Standards
IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3az
Bays
2 (total) / 1 (free) x internal 2.5"
Slots
1 (total) / 0 (free) x CPU ¦ 2 (total) / 1 (free) x SO-DIMM 204-pin
Interfaces
6 x USB 2.0 ¦ 2 x PoweredUSB (12 V) ¦ 1 x PoweredUSB (24 V) ¦ 1 x USB ¦ 1 x cash drawer ¦ 2 x serial ¦ 1 x parallel ¦ 1 x PS/2 keyboard / mouse ¦ 1 x DVI-I ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x audio line-in ¦ 1 x audio line-out
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Mounting Interface
100 x 100 mm
Compliant Standards
RoHS, WEEE
Device Type
Power adapter
Nominal Voltage
AC 120/230 V (50/60 Hz)
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Microsoft Windows Embedded POSReady 7 64-bit
OS Certified
SUSE Linux Enterprise Desktop
EPEAT Compliant
EPEAT Gold
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Min Operating Temperature
10 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 85%
